0-5H-H1-2MM-12

0.5H H1.2mm 12P 1.27mm Male Socket FPC Connector

0.5mm pitch 12P male socket FPC connector, 9T

0.5mm pitch H1.2mm 12P male socket FPC connector, 1.27mm pins, reliable contact. 9T hi-temp material, rated current 0.4A, withstand 200V AC/min, insulation ≥500MΩ, contact ≤0.02Ω, -20℃~+84℃. ODM/OEM, MOQ 1000pcs, lead time 7-15 days, made in Dongguan, Guangdong. (Specs by default, please verify.)

Specifications

MOQ1000pcs
TypeSocket
Pitch0.5mm
Poles12
GenderMale
Material9T Hi-temp Material
Lead Time7-15 days
PackagingBag + Carton
ApplicationFPC / FFC
Current Rating0.4A AC/DC
Voltage RatingAC,DC 50V (50Hz)
Place of OriginGuangdong, Dongguan, China
Withstand Voltage200V AC/min
Contact Resistance≤0.02Ω
Working Temperature-20℃ ~ +84℃
Insulation Resistance≥500MΩ
